Product Details
＋
Typical Uses for C93800 High Leaded Tin Bronze "SAE 67":
INDUSTRIAL: Railroad Engine Casings, General Service Bearings for Moderate Pressure, Wearing Material for Rod Bushings, Wearing Material for Wedges, Wearing Material for Shoes, Pump Impellers for Acid Mine Water, Pump Bodies for Acid Mine Water, Freight Car Bearings, Backs for Lined Journal Bearings for Locomotives, Backs for Lined Journal Bearings for Passenger Cars, Bearings, Pumps, Industrial Centrifuges, Machine Parts, Low Friction, Moderate Pressure Bushings, Railroad Applications, Acid Resisting Applications
MARINE: Large Bearings for Ships
| Al | Sb | Cu | Fe | Pb | Ni | P | Si | S | Sn | Zn | |
| Min/Max | 0.005 | 0.8 | 75.0 - 79.0 | 0.15 | 13.0 - 16.0 | 1 | 0.05 | 0.005 | 0.08 | 6.3 - 7.5 | 0.8 |
| Nominals | - | - | 77.0000 | - | 14.5000 | - | - | - | - | 6.9000 | - |
| Product Type | Temper Type |
| Centrifugal | ASTM B271, SAE J461, J462 |
| Continuous | ASTM B505, SAE J462, J461 |
| Ingot | ASTM B30 |
| Prermanent | SAE J461, J462 |
| Sand | AMS 4842, ASME SB584, ASTM B763, B66, B584, B22, SAE J461, J462 |
| Temper | Sect. Size | Cold Work | Type Min | Temp | Tensile Strength | YS 0.05% UL | YS 0.02% Offset | YS 0.005% Offset | Elong. | RH B | RH C | RH F | RH 30T | VH 500 | BH 500 | BH 3000 | Shear Strgth | Fatigue Strgth | Izod Impact Strgth |
| - | in. | % | - | F | ksi | ksi | ksi | ksi | % | B | C | F | 30T | 500 | 500 | 3000 | ksi | ksi | ft-lb |
| - | mm. | - | - | C | MPa | MPa | MPa | MPa | - | - | - | - | - | - | - | - | MPa | MPa | J |
| As Centrifugal Cast | |||||||||||||||||||
| M02 | 68 | 33 | 20 | - | - | - | - | - | - | - | - | - | - | - | - | ||||
| M02 | 0 | TYP | 20 | 228 | 138 | - | - | 12 | - | - | - | - | - | - | - | - | - | 0 | |
| M02 | 68 | 26 | 14 | - | - | - | - | - | - | - | - | - | - | - | - | ||||
| M02 | 0 | SMIN | 20 | 179 | 97 | - | - | 12 | - | - | - | - | - | - | - | - | - | 0 | |
| As Continous Cast | |||||||||||||||||||
| M07 | 68 | 25 | 16 | - | - | - | - | - | - | - | - | - | - | - | - | ||||
| M07 | 0 | SMIN | 20 | 172 | 110 | - | - | 5 | - | - | - | - | - | - | - | - | - | 0 | |
| As Sand Cast | |||||||||||||||||||
| M01 | 68 | 26 | 14 | - | - | - | - | - | - | - | - | - | - | - | - | ||||
| M01 | 0 | SMIN | 20 | 179 | 97 | - | - | 12 | - | - | - | - | - | - | - | - | - | 0 | |
| M01 | 68 | 30 | 16 | - | - | - | - | - | - | - | - | - | - | 15 | 10 | 5 | |||
| M01 | 0 | TYP | 20 | 207 | 110 | - | - | 18 | - | - | - | - | - | 55 | - | 103 | 69 | 7 |
| Product Property | US Customary | Metric |
| Coefficient of Thermal Expansion | 10.3 . 10-6 per oF (68-392 F) | 18.5 . 10-6 per oC (20-300 C) |
| Density | 0.334 lb/in3 at 68 F | 9.25 gm/cm3 @ 20 C |
| Electrical Conductivity | 11 %IACS @ 68 F | 0.066 MegaSiemens/cm @ 20 C |
| Electrical Resistivity | 91.1 ohms-cmil/ft @ 68 F | 15.15 microhm-cm @ 20 C |
| Incipient Melting | 600 oF | 316 C |
| Magnetic Permeability | 1 | 1 |
| Melting Point - Liquidus | 1730 F | 943 C |
| Melting Point - Solidus | 1570 F | 854 C |
| Modulas of Elasticity in Tension | 10500 ksi | 72400 MPa |
| Specific Gravity | 9.25 | 9.25 |
| Specific Heat Capacity | 0.09 Btu/lb/oF at 68 F | 377.1 J/kg . oK at 293 K |
| Thermal Conductivity | 30.2 Btu . ft/(hr . ft2 . oF)at 68F | 52.3 W/m . oK at 20 C |
| Joining Technique | Suitability |
| Brazing | Poor |
| Coated Metal Arc Welding | Not Recommended |
| Gas Shielded Arc Welding | Not Recommended |
| Machinability Rating | 80 |
| Oxyacetylene Welding | Not Recommended |
| Soldering | Good |
| End Product | Specification |
| Centrifugal | ASTM B271, SAE J461, J462 |
| Continuous | ASTM B505, SAE J462, J461 |
| Ingot | ASTM B30 |
| Prermanent | SAE J461, J462 |
| Sand | AMS 4842, ASME SB584, ASTM B763, B66, B584, B22, SAE J461, J462 |
